Product Details:
Payment & Shipping Terms:
|
| SIZE: | 1/4" - 2" | Working Pressure: | 150PSl |
|---|---|---|---|
| Medium: | Water,Oil,air And Some Corrosive Liqid | Thread Type: | G.NPT.BSPT.BSP.DIN259/2999 |
| Structure: | Ball,full Port | Material: | Stainless Steel,Brass,WCB,PVC |
| Power: | Manual,Pneumatic,Electric,motorized | Pressure: | Low Pressure |
| Media: | Water,oil,Gas,Air,Liquid | Port Size: | 1/2in-8in |
| Application: | General,Household Usage,SGS,Industrial Usage | Product Name: | Hydraulic Ball Valve,Wholesale Professional Plastic PVC/UPVC Ball Valve,New Mould Ppr Fittings Double Union Plastic Ball Valve,UPVC Manual Ball Valve,UPVC True Union Ball Valve |
| Body Material: | Stainless Steel 316,304 | Size: | 1/8"~4" |
| Standard: | DIN,ASTM,ANSI,DIN/ JIS / ANSI /BS/CNS | Working Pressure: | 0-10 Bar |
| Connection: | Thread BSP NPT,Flange Ends,Female Thread/OD Size,threaded,Female | Usage: | Control Water Flow |
| Seal Material: | PTFE,Silicon,VITON | ||
| High Light: | 2 inch stainless steel ball valve,thread ball valve |
||
|
NO. |
Part Name
|
Material
|
|
1
|
Joint ring
|
PTFE
|
|
2
|
Ball
|
304/316
|
|
3
|
Joint gasket
|
PTFE
|
|
4
|
Cap
|
304/316
|
|
5
|
Body
|
304/316
|
|
6
|
Stem
|
304/316
|
|
7
|
Thrust washer
|
PTFE
|
|
8
|
Stem packing
|
PTFE
|
|
9
|
Gland nut
|
304
|
|
10
|
Stem washer
|
304
|
|
11
|
Stem nut
|
304
|
|
12
|
Handle cover
|
Plastic
|
|
13
|
Handle
|
304
|
|
SIZE |
1/4"
|
3/8"
|
1/2"
|
3/4"
|
1"
|
1-1/4"
|
1-1/2"
|
2"
|
|
D
|
5
|
7
|
9.2
|
12.5
|
15
|
20
|
24.5
|
32
|
|
L
|
40
|
45
|
58
|
60
|
72
|
78
|
83
|
100
|
|
H
|
35
|
37
|
43.5
|
47
|
50
|
57
|
69
|
74.5
|
|
E
|
64
|
70
|
90
|
90
|
103
|
103
|
127
|
127
|
|
WT(g)
|
55
|
95
|
165
|
250
|
405
|
625
|
850
|
1400
|
