Product Details:
Payment & Shipping Terms:
|
| Media: | Water,Oil,Gas | Power: | Manual |
|---|---|---|---|
| Pressure: | Medium Pressure,Low Pressure | Structure: | Gate |
| Product Name: | GATE VALVE | Standard: | ANSI BS DIN JIS,DIN |
| Body Material: | Brass Or Bronze | Working Pressure: | 1.0-1.6Mpa (10-25bar) |
| Connection: | Female Thread | ||
| High Light: | 25bar bronze gate valve,ISO228 bronze gate valve,25bar metal gate valve |
||
1. Nominal Pressure: 1.6Mpa
2. Working Medium: Water, Non-causticity liquid, Non-combustible Gas & Saturated Steam.
3. Working Temperature: -10 oC ≤t≤ 100oC.
4. Taper Pipe Thread to ANSI B1.20.1, BSP, NPT, etc
5. Size: 1/2", 3/4", 1", 1 1/4", 1 1/2", 2".
Technical standard
-1. Normal pressure: 1.6Mpa
-2. Working medium: water, gas, oil
-3. Working temperature: -20ºC≤T≤120ºC
-4. Thread standard: ISO228
FAQ:
Q1: Can I have a sample before placing the order?
A: Yes, we would like to provide you samples for testing and checking before quantity purchasing
Q2: What is your MOQ order?
A: Usually 3000 for ordinary products, and 5000pcs for product needs new mold.
Q3.How to proceed an order for your products?
A: Firstly, pls let us know your requirments and application
Seconly, we provide quotation accordingly or suggestion
Thirdly, samples confirmation
Forth, place order and deposit and production arrangement.
